All advantages of the Jinbei 4-Honeycomb Set at a glance:

• Four different grids for different light bundling
• Directed, harder light
• More control over the lighting
• Easy to put on
• For fashion, beauty, glamor and portrait shots

Flexibly applicable Jinbei honeycomb set of 4 for reflector 55 portablel

TheJinbei honeycomb set of 4 for the Jinbei reflector 55 portablel additionally limits the spread of the emitted light. Thefour grids WithLighting angles fromten to forty degrees narrow the light beam differently and generate a correspondingly intense, more directional, harder light.

With theGrid set illuminate your motif more precisely and in a more controlled manner and have a lot of leeway in terms of focusing the light.

Please note that the honeycomb set only fits the Jinbei reflector 55 portable..

Specifications & amp; scope of delivery

All the advantages of the 5-in-1 collapsible reflector at a glance:

• Perfect the light
• Various light characteristics can be achieved
• Easy to fold
• Ideal for on the go
• Compatible with theRBJ-130 universal reflector holder

5-in-1 collapsible reflector perfects the light

The Jinbei 5-in-1 collapsible reflector directs the light from your studio flash, your LED permanent light or natural light specifically onto the object or model to be photographed. At the same time, you can perfect your photos by changing the characteristics of the light with the colored reflective surfaces or the diffuser.

One diffuser and four colors

The folding reflector set consists of a round, 80 or 110 centimeter large Diffuser as a basic structure and a coating in the colors Silver, black, gold and white . To switch between the colors, open the cover with the zipper and turn it over to match.

The Jinbei 5-in-1 collapsible reflector set is ideal for the mobile use because it is quick to set up, fold up and easy to transport

• The silver surface increases the contrasts
• The black surface avoids scattered light and shadows the subject
• The golden surface creates warm light - ideal for skin tones
• The white surface illuminates the subject with neutral, soft light
• The diffuser scatters the light and creates soft shadows

Technical data & scope of delivery

All advantages of the A-3 triple flash and umbrella adapter at a glance:

• Three flashes can be used at the same time
• For clip-on flashes with standard ISO flash base not suitable for Minolta and not for all Sony flash unitse)
• Built-in tilt mechanism
• Umbrella holder
• Easy mounting on a tripod

A-3 triple flash and umbrella holder with three flash shoes

Of the Jinbei A-3 triple flash and umbrella holder can be placed horizontally or vertically on any tripod up to approximately 15 millimeters thick and mounted with the practical locking screw. In theie three hot shoes Flashes with standard ISO flash feet do not fit Minolta and not all Sony flash units.).

The simultaneous use of three flash units offers a multitude of possible uses. When using reflex umbrellas, it may make sense to use several flash units aligned in the same direction in order to achieve sufficiently strong lighting.

There is one directly under the flash holder Studio umbrella holder. This flash holder is pronounced by the built-in tilt mechanism flexible use.

scope of delivery

All advantages of the battery set at a glance:

• Battery set suitable for the EFT-360 RGB LED tube light
• Consists of 2 batteries with 18.5 Wh and a double charger

Here you get one Battery set for the newStick light EFT-360 RGB. It off two batteries as well as one Double charger .

This enables you to always be one on your shoots couple of replacement batteries to have with you so that you can be completely on your toes the shoot can concentrate without having to keep an eye on the battery..

The running time is about 75 minutes , where the Lithium-ion batteries an energy of 18.5 watt hours and the charger has a Charging voltage of 3.7 volts owns.

Jump into your photo shoots! With the Battery set for yourStick light EFT-360 RGB.

Technical data, scope of delivery & downloads

All advantages of the EFD-300 LED permanent light at a glance:

• The device consists of the light head and the control box, so that it can also be operated easily when it is mounted on the ceiling, for example
• Dual power supply, mains or battery possible. Batteries not includeden)
• 300 W power continuously adjustable
• 5500 K color temperature similar to daylight
• 5 different light effects with 10 frequencies each
• Ideal for video recordings
• App operation
• The fan can be switched off at a maximum output of 300%)
• CRI color rendering index over 97 & TLCI over 98
• over 49,500 lx illuminance at 0.5 m without reflector
• Bowens S-type for maximum compatibility
• 32 channels, 16 groups, compatible with EF-RCRemote control for LED permanent lights
• Incl. Practical transport bag

The Jinbei LED permanent light EFD-300 with 300 watts of power

Our Continuous light EFD-300 is with 300 watts the little brother of theEFD-500 and offers a Daylight-like color temperature of 5500 K and five different lighting effects, each with ten frequencies, which are absolutely ideal for Video recordings . Of the Color rendering index CRI of the light is included over 97 . The TLCI Television Lighting Consistency Index, a key figure for evaluating lighting quality, is over 98.8.

But the illuminance of the device is also remarkable. The EFD-300 comes with 207,000 lux at 0.5 meters with reflector . Light setups can be done in 32 channels and 16 groups be divided, which makes the preparation of shootings easier. In addition, the device is compatible with the Remote control EF-RC operable and also has a DMX-512 control.

The EFD-300 is used as a Set of light head and control box With practical accessories sold. The special thing about it: the light head can be operate on the control box . This allows users to mount the light on the ceiling, for example, and not only on the control box, but even from the floor operate via app : Android:Jinbei Studio; iOS:Jinbei.

It can via power supply and also battery pack can be supplied with power, whereby the batteries are not included in the scope of delivery but can be purchased separately. Also a big one Selection of light shapers is thanks Bowens S-type bayonet usable, which promises maximum compatibility

Technical data, scope of delivery & downloads

Power:	300 watts
Energy efficiency class:
Spectrum:	A -D -D
Power control:	0 100, in 1 stepsten
Color temperature:	5500 K 200 KK
Color rendering index CRI:):	& gt; 97
Television Lighting Consistency Index TLCI:):	& gt; 98
Illuminance:	49,500 lx 0.5 m, without reflectorr) 12,500 lx 1 m, without reflectorr)
Channels:	32 channels 00 3131)
Groups:	16 groups A J / L / O / P / Q / S / U U)
Light effects:	TV Flickering lightbulb Fireworks Thunderstorm mode Flashing mode - each has a frequency of 1 - 10- 10
Bluetooth version:	4.2
Frequency band:	2.402 - 2.480 GHz
Max. Radiated transmission power:	6 dBm
Bowens S-type bayonet:	Yes
Battery operation:	Battery operation with 1 or 2 V-mount batteries possible on control box not includedn Note: The EFD-300 can achieve half the power with one and full power with two V-mount batteries 14.4 V / 10 A, 14.8 V / 10 A, 26 V / 8.5 A, 28.8 V. / 29.6 V / 7.5 A.).
Battery life:	1 V-mount battery: max. 90 W 26 V, 290 Wh:: 100 power: 107 minn 50 power: 214 minn 10 power: 1070 minn 2 V-Mount batteries: max. 300 W 26 V, 290 Wh:: 100 power: 96 minn 50 power: 192 minn 10 power: 960 minn 2 V-Mount batteries: max. 300 W 14.8 V, 220 Wh:: 100 power: 85 minn 2 V-Mount batteries: max. 300 W 14.8 V, 290 Wh:: 100 power: 105 minn 2 V-Mount batteries: max. 300 W 26 V, 260 Wh:: 100 power: 92 minn
Power supply:	Light head: Input: 56 V DC max. 5 A 280 W. W Control box: Input: 100 240 V AC 50/60 Hz max. 2.9 A 320 W.20 W Input: 14.4 - 33.6 V DC max. 10 A 300 W. W Output: 56 V DC max. 5 A 280 W. W
Remote control:	Integrated 2.4GHz range & gt; 100 m m
Compatible remote control:	EF-RC remote control for LED permanent lights
Bluetooth function:	App operation "Jinbei Studio", range & gt; 15 m m Note on the language setting of the Jinbei app
Further equipment:	Control box with LC display Light head with umbrella holder, tripod attachment, carrying handle, U bracketung Fan volume fan: & lt; 35 dB, can be switched off with a maximum output of 30 %) Beam angle 1200° DMX 512 control Control box bracket compatible with light stands with a central column diameter of 30 40 mmm
Dimensions:	Light head: 28 x 19 x 20 cm Control box: 11.5 x 14.5 x 29.5 cm Control box power cord: 4.20 m Cable control box - light head: 3 m
Weight:	Light head: 2.7 kg Control box: 3.1 kg
Downloads:	To the download center
Scope of delivery:	1x EFD-300 light head 1x EFD-300 control box 1x EF-7 "reflector 70° 1x light stand holder for the control box 1x protective cap 1x power cord control box - sockete) 1x cable light head - control boxx) 1x carrying bag
